Max Torque = 0.4 to 50.1Nm (0.3 ft-lbf to 37 ft-lbf)

Max Speed = 428 to 3000 RPM

Working Window = 1500 * 1800 mm (59* 71 inch)

Power Supply = 200-240V 50/60Hz

For Tube OD = 1/4 to 1.5 inch

·  Dual motors working simultaneously, allowing for the expansion of two tube holes at once

·  Customizable to accommodate various tube pitches

·  Automatic mode for continuous expansion, saving time and effort

·  Cantilever balance for safety and ease of use

·  User-friendly design with built-in torque calculator

·  Integrated metric and imperial unit converter

·  Real-time motor output monitoring

·  Built-in Torque recorder

·  one-click to download historical data

·  Program updates via USB drives

SRD400/750 Specifications
